Images with Smaller Telescopes

The images below were obtained with a 235mm Celestron Schmidt Cassegrain telescope or a 130mm Sharpstar apochromatic refractor located in North Ryde, Sydney.

Sony IMX290 or IMX178 CMOS sensors, RGB filters or SDSS g' and r' filters. The colour images are made by combining images in R, G and B filters each being itself a composite of ~1000 or more individual short exposures.  The rotation sequences are obtained by repeating observations every five minutes approximately. Processing with AutoStakkert (frame registration and combination), Registax 6 (multiscale sharpening), Astra Image (RGB combination) and GIF Brewery 3 (animated GIF creation).

2019 Aug 13  UT 08:05 - 10:20   (235 mm Telescope)

2019 Aug 2  UT 09:38 - 12:50 showing transit and shadow of Io   (235 mm Telescope)

2019 Jul 25  UT 07:49 - 12:00   Io going into occultation behind Jupiter (130 mm Telescope)

2019 Jul 19  UT 08:07 - 12:15 —  Shadow of Io at start (130 mm Telescope)

2019 Jun 26  UT 10:36 - 12:50 —  Transit and shadow of Ganymede (130 mm Telescope)

2019 Jun 19 UT 11:17 - 12:50 (130 mm Telescope)

g' filter

r' filter

2019 Jun 14 UT 11:06 - 13:10

2019 Jun 14 UT 14:06 - 15:40

g' filter

 Saturn   -  235 mm Telescope -   2019 Aug 6

g'

r'
